North American Numbering Plan (NANP)

Table of Content

Please enable JavaScript in your browser to complete this form.

Introduction

The North American Numbering Plan (NANP) is a telephone numbering system that serves 20 countries and territories, primarily in North America and the Caribbean. It is a unified framework that enables seamless communication across international borders. In this comprehensive guide, we’ll explore the history, structure, and modern developments of the NANP.

History of the NANP

The NANP has its roots in the 1940s when AT&T and the Bell System devised a plan to standardize telephone numbering across North America.

Subheading 2.1: Origins and Implementation

  • Developed by AT&T and Bell System in the 1940s
  • Implemented in 1947 with 86 numbering plan areas (NPAs)
  • Expanded throughout the 20th century

Administration

The administration of the North American Numbering Plan has evolved to meet the changing needs of the telecommunications industry.

Initially, the NANP was administered by AT&T’s Central Services Organization, which was responsible for overseeing the assignment of area codes and central office codes. This arrangement continued until the breakup of the Bell System in 1984.

After the Bell System’s divestiture, the administration of the NANP was transferred to Bell Communications Research (Bellcore), a newly created company tasked with providing services to the regional Bell operating companies. Bellcore assumed the role of the North American Numbering Plan Administrator (NANPA) and maintained this responsibility until 1997.

In 1997, the Federal Communications Commission (FCC) awarded the NANPA contract to Lockheed Martin’s IMS division, which managed the NANP until 1999. Subsequently, the contract was awarded to Neustar, Inc., a company spun off from Lockheed Martin for this purpose. Neustar held the NANPA role from 1999 to 2018, during which time it oversaw the introduction of new area codes and the implementation of number conservation measures such as number pooling and rate center consolidation.

In 2018, the FCC selected Somos, Inc., a non-profit entity, as the new NANPA. Somos assumed the role on January 1, 2019, under a one-year bridge contract, with the aim of consolidating the NANPA and Pooling Administrator (PA) functions and identifying a long-term contractor. On December 1, 2020, Somos secured an eight-year, $76 million contract to continue serving as the NANPA.

The NANPA’s responsibilities include:

  1. Assigning area codes and central office codes
  2. Monitoring numbering resource utilization
  3. Forecasting the exhaust of numbering resources
  4. Planning for area code relief (splits or overlays)
  5. Maintaining numbering databases
  6. Providing industry notification of numbering plan changes
  7. Coordinating with regulatory authorities and industry stakeholders

Throughout its history, the administration of the NANP has adapted to meet the evolving challenges of the telecommunications landscape, ensuring the efficient allocation and management of numbering resources across the participating countries and territories.

NANP Structure

NANP Structure

The North American Numbering Plan follows a standardized structure to ensure efficient routing and management of telephone numbers across its member countries and territories. This structure is designed to accommodate a large number of telephone subscribers while maintaining a logical and hierarchical organization.

Numbering Plan Areas (NPAs) and Area Codes

At the highest level of the NANP structure are the Numbering Plan Areas (NPAs). Each NPA corresponds to a specific geographical region, such as a state, province, or group of smaller territories. In some cases, particularly in densely populated areas, a single geographical region may be served by multiple NPAs.

Each NPA is assigned a unique three-digit code, known as an area code. Area codes are the first three digits of a ten-digit telephone number and serve as a prefix to identify the NPA. For example, the area code 212 is associated with New York City, while 416 represents Toronto, Canada.

Originally, area codes followed a specific format, with the middle digit being either 0 or 1. However, as the demand for telephone numbers grew, this restriction was lifted in 1995, allowing area codes to have any digit except 9 as the middle digit.

Central Office Codes and Line Numbers

Within each NPA, telephone numbers are further divided into Central Office Codes (COCs) and Line Numbers. The COC, also known as the prefix or exchange code, is the second set of three digits in a telephone number (NXX). It identifies a specific central office or telephone exchange within the NPA.

Like area codes, central office codes have certain restrictions. Traditionally, they could not begin with 0 or 1, as these digits were used for operator assistance and special services. However, with the increasing demand for telephone numbers, this restriction was also lifted, allowing central office codes to start with any digit except 1.

The final four digits of a telephone number (XXXX) are the Line Number, which identifies a specific subscriber within the central office. Line numbers range from 0000 to 9999, providing a pool of 10,000 possible numbers for each central office code.

Together, the combination of NPA, COC, and Line Number creates a unique ten-digit telephone number in the format NPA-NXX-XXXX. This format allows for a theoretical maximum of 6.4 billion unique telephone numbers within the NANP.

Table: NANP Number Format

The table below illustrates the breakdown of a typical NANP telephone number:

ComponentNameNumber Ranges
NPANumbering Plan Area Code200-999
NXXCentral Office Code200-999
XXXXLine Number0000-9999

For example, the telephone number is 212-555-1234:

  • 212 is the NPA (area code) for New York City
  • 555 is the COC (central office code) for a specific exchange within New York City
  • 1234 is the Line Number identifying the individual subscriber

This structured approach to telephone numbering has allowed the NANP to efficiently manage the allocation of numbers across its member countries and territories, ensuring a consistent and organized system for routing calls and identifying subscribers.

Decoding the Secret of NPA NXX

Expansion and Growth

Expansion and Growth

As the demand for telephone numbers increased in the late 20th century, the North American Numbering Plan underwent significant changes to accommodate growth. These changes were necessary to ensure an adequate supply of telephone numbers for new subscribers and to manage the efficient allocation of numbering resources.

Interchangeable Codes

One of the most significant changes to the NANP was the introduction of interchangeable NPA (Numbering Plan Area) codes in 1995. Before this change, area codes followed a strict format, with the middle digit being either 0 or 1. This limited the total number of available area codes and restricted the flexibility of the numbering system.

The introduction of interchangeable NPA codes allowed the use of digits 2 through 8 as the middle digit in area codes, greatly expanding the pool of available codes. This change enabled the creation of new area codes such as 334 (Alabama) and 360 (Washington), which would not have been possible under the previous system.

The implementation of interchangeable NPA codes was a crucial step in accommodating the rapid growth in demand for telephone numbers, particularly in areas with high population densities or rapidly expanding telecommunications markets.

Overlay Plans and Ten-Digit Dialing

Another significant development in the NANP’s expansion was the introduction of overlay plans. Traditionally, when an area code neared exhaustion, the numbering plan area would be split into two or more smaller geographic regions, each with its area code. While this approach effectively increased the supply of available numbers, it also required customers to change their existing phone numbers, which was often met with resistance and confusion.

Overlay plans offered an alternative solution by assigning multiple area codes to the same geographical area. Under an overlay plan, a new area code is introduced to serve the same region as an existing area code, with both codes being used simultaneously. This approach allows existing customers to retain their phone numbers while providing a new pool of numbers for future growth.

However, the introduction of overlay plans also necessitated a change in dialing behaviour. In areas with overlays, ten-digit dialing became necessary for all local calls, even those within the same area code. This change was required to ensure that calls were routed correctly between the overlapping area codes.

One notable example of an overlay plan is in Atlanta, Georgia. The city was originally served by the 404 area code, but as demand for numbers grew, the 770 area code was introduced as an overlay in 1995. Customers with existing 404 numbers retained their numbers, while new subscribers were assigned numbers with the 770 area code. Ten-digit dialing became mandatory for all local calls within the Atlanta metropolitan area.

The use of overlay plans has become increasingly common in the NANP as a means of managing number exhaust and accommodating growth. While ten-digit dialing can be an adjustment for customers, it has proven to be an effective solution for extending the life of the numbering plan and ensuring a sufficient supply of telephone numbers for future demand.

In conclusion, the introduction of interchangeable NPA codes and overlay plans has been instrumental in the NANP’s ability to accommodate the rapid growth in demand for telephone numbers. These changes have provided greater flexibility and efficiency in the allocation of numbering resources while minimizing disruption to existing customers. As the telecommunications landscape continues to evolve, the NANP will likely continue to adapt and implement new strategies to meet the changing needs of its member countries and territories.

Modern Developments

The North American Numbering Plan continues to evolve to meet the changing needs of the telecommunications industry. As new technologies emerge and the demand for telephone numbers persists, the NANP has implemented various strategies to ensure the efficient use of numbering resources and to extend the life of the current numbering system.

Subheading 5.1: Number Pooling and Conservation Measures

One of the most significant modern developments in the NANP has been the implementation of number pooling. Traditionally, telephone numbers were allocated to service providers in blocks of 10,000, which often led to inefficient use of numbering resources. Many service providers would not use all the numbers allocated to them, resulting in large pools of unused numbers.

To address this issue, the NANP introduced number pooling, which allows numbers to be allocated in smaller blocks of 1,000. This approach enables more efficient use of numbering resources by allowing multiple service providers to share a single central office code (NXX) and reduces the need for new area codes.

Another conservation measure implemented by the NANP is rate center consolidation. A rate center is a geographical area used by service providers to determine local calling boundaries and to assign telephone numbers. Historically, each rate center was assigned its own central office code, leading to the underutilization of numbers in areas with low population densities.

Rate center consolidation involves combining multiple rate centers into a single, larger area, allowing for the more efficient use of numbering resources. By consolidating rate centers, service providers can assign numbers from a single central office code across a larger geographic area, reducing the need for additional area codes.

These conservation measures, along with others such as number reclamation and the implementation of overlay plans, have helped to delay the exhaust of area codes and extend the life of the NANP. By using numbering resources more efficiently, the NANP has been able to meet the growing demand for telephone numbers without the need for major structural changes.

Potential Future Expansion

Despite the effectiveness of number pooling and other conservation measures, the NANP will eventually face the need for expansion as the demand for telephone numbers continues to grow. According to a 2019 NANP exhaust analysis, the current numbering system can support the needs of the member countries and territories beyond 2049, assuming an average of 3,990 central office codes assigned per year [1].

However, planning for the eventual expansion of the NANP is an ongoing process. One possible expansion plan involves adding one or more digits to the existing ten-digit numbering format. This could be achieved by either adding a digit to the beginning of the area code (e.g., creating four-digit area codes) or by adding a digit to the end of the line number (e.g., creating seven-digit line numbers).

Another potential expansion plan involves the use of the digit 9 as the middle digit in new area codes. Currently, the digit 9 is not used as the middle digit in any area code, providing a pool of unused codes that could be assigned in the future.

The specific details of any future expansion plan will depend on a variety of factors, including the projected demand for telephone numbers, the technical feasibility of implementing the changes, and the potential impact on customers and service providers. The NANP administration, in collaboration with regulatory authorities and industry stakeholders, will continue to monitor the numbering landscape and develop strategies to ensure the long-term viability of the numbering system.

In conclusion, the modern developments in the NANP, such as number pooling and conservation measures, have played a crucial role in extending the life of the current numbering system and ensuring the efficient use of numbering resources. As the demand for telephone numbers continues to grow, the NANP will need to adapt and evolve to meet the changing needs of the telecommunications industry. Through careful planning and collaboration, the NANP will be well-positioned to address the challenges of the future and maintain its role as a vital component of the global telecommunications infrastructure.

What is NPA?

What is NPA

NPA stands for Numbering Plan Area, which is a geographical region in the North American Numbering Plan (NANP) assigned with a specific three-digit telephone area code. Key points about NPAs include:

  1. An NPA is identified by a unique three-digit code, commonly known as an area code.
  2. The area code is the first three digits of a ten-digit telephone number in the NANP format.
  3. NPAs can correspond to an entire state or province, a portion of a state or province, or a major metropolitan area.
  4. In some cases, multiple NPAs may serve the same geographical area, a practice known as an overlay plan.
  5. Originally, the second digit of an NPA was either 0 or 1. However, this restriction was relaxed in 1995 to allow the use of digits 2 through 8 to accommodate the increasing demand for telephone numbers.
  6. The first digit of an NPA is always in the range of 2-9, and the third digit cannot be 9 (as of 2023).
  7. There are currently three formats for NPAs: NXX, where N is any digit 2-9 and X is any digit 0-9; N1X, which is reserved for special services (e.g., 800 for toll-free); and N9X, which has been set aside for future expansion.

NPAs are a fundamental component of the NANP, allowing for the efficient routing and management of telephone calls across the member countries and territories.

What is NXX?

NXX is the format used for the three-digit central office code (COC) in the North American Numbering Plan (NANP). The COC is the second set of three digits in a ten-digit telephone number, following the area code (NPA). Key points about NXX include:

  1. In the NXX format, N represents any digit from 2 to 9, and X represents any digit from 0 to 9.
  2. The central office code identifies a specific telephone exchange or switch within an NPA.
  3. Each COC can support up to 10,000 individual telephone numbers (0000-9999).
  4. Originally, the first two digits of the COC could not be 0 or 1, as these digits were used for operator assistance and special services. However, this restriction was lifted to allow for the use of any digit except 1 as the first or second digit of the COC.
  5. Certain NXX codes are reserved for special purposes, such as 555 for directory assistance or fictional telephone numbers in movies and television shows.
  6. Some NXX codes, such as N11 (e.g., 211, 411, 911), are used for special services like community information, directory assistance, and emergency services.
  7. The combination of the NPA and NXX (NPA-NXX) is often referred to as a telephone prefix or exchange.

Together, the NPA (area code) and the NXX (central office code) form a unique six-digit prefix that identifies a specific geographic area and telephone exchange within the NANP. The remaining four digits (XXXX) identify an individual subscriber line within that exchange.

Learn how to order NPA NXX codes

What is NANP?

NANP stands for the North American Numbering Plan, which is a telephone numbering system used in 20 countries and territories, primarily in North America and parts of the Caribbean. The NANP is a unified framework that enables efficient routing and management of telephone calls across its member regions. Key points about the NANP include:

  1. The NANP was developed by AT&T and the Bell System in the 1940s and implemented in 1947 to standardize telephone numbering across North America.
  2. It is administered by the North American Numbering Plan Administrator (NANPA), a role currently held by Somos, Inc.
  3. The NANP follows a standardized ten-digit telephone number format: NPA-NXX-XXXX, where NPA is the three-digit area code, NXX is the three-digit central office code, and XXXX is the four-digit subscriber line number.
  4. The NANP is divided into Numbering Plan Areas (NPAs), each identified by a unique three-digit area code.
  5. The NANP has evolved to accommodate the growing demand for telephone numbers through various measures, such as the introduction of interchangeable area codes, overlay plans, and number pooling.
  6. Member countries and territories of the NANP share the country calling code +1.
  7. As of 2023, the NANP member regions include the United States and its territories, Canada, Bermuda, and 17 Caribbean nations.
  8. The NANP is expected to have sufficient capacity to support the needs of its member regions beyond 2049, based on current projections and numbering resource conservation efforts.

The NANP plays a critical role in facilitating seamless communication across its member countries and territories, enabling efficient routing of telephone calls and the effective management of numbering resources

Conclusion

The North American Numbering Plan has been instrumental in facilitating seamless communication across North America and parts of the Caribbean. Through its unified structure and continuous evolution, the NANP has adapted to the growing demands of the telecommunications industry. As technology advances, the NANP will likely continue to evolve to meet the needs of the future.

References:

[1] North American Numbering Plan Administrator. (2019). April 2019 North American Numbering Plan (NANP) Exhaust Analysis. Retrieved from URL
